The Audio-Technica VM610MONO is a dedicated mono playback moving-magnet cartridge engineered with a 0.6 mil bonded conical stylus and dual magnets internally linked for enhanced mono clarity. Designed for faithful reproduction of mono LPs, it delivers a focused center image, minimized surface noise, and a robust 3 mV high output—perfect for audiophiles rediscovering vintage mono records.

Feature Specifications – Audio-Technica VM610MONO

• Cartridge Type: Dual Moving-Magnet (VM series) with mono-specific body and internal wiring for true mono reproduction.

• Stylus Shape & Size: 0.6 mil bonded conical — smooth groove tracking and timeless tone.

• Cantilever: Aluminum pipe — lightweight and resonance-resistant.

• Output Voltage: 3.0 mV (at 1 kHz, 5 cm/s) — ample signal for phono preamps.

• Frequency Response: 20 Hz – 20 kHz — full-range warmth and detail.

• Tracking Force: 1.8–2.2 g; 2.0 g standard — optimal groove penetration.

• Vertical Tracking Angle (VTA): 23° — aligned for accurate tracking.

• Electrical Specs:

  • Coil Impedance: 1.4 kΩ (1 kHz)

  • DC Resistance: 400 Ω

  • Coil Inductance: 230 mH (1 kHz)

  • Recommended Load Impedance: 47 kΩ

  • Recommended Load Capacitance: 100–200 pF

• Compliance: Static 35 × 10⁻⁶ cm/dyne; Dynamic 8 × 10⁻⁶ cm/dyne @100 Hz — matches most tonearms effectively.

• Mount & Dimensions: Standard half-inch mount; 17.3 × 17.0 × 28.2 mm; Weight 6.4 g.

• Replacement Stylus: VMN10CB — easy maintenance when the stylus wears.

• Extra Features:

  • Paratoroidal coils for efficient signal output

  • Mono body design reduces surface noise

  • Durable, low-resonance polymer housing for clean playback
